Precision-Engineered UIC54 Rail Fishplate 4 Holes for Railway Fastening System

Name: PrecisionEngineered UIC54 Rail Fishplate 4 Holes for Railway Fastening System
Brand: Gnee Rail
Price: 1 USD

Wholesale Precision-Engineered UIC54 Rail Fishplate 4 Holes for Railway Fastening System from china suppliers

Brand Name : Gnee Rail

Model Number : Oval Neck Track Head Bolts

Certification : ISO

Place of Origin : China

MOQ : 1 Tons

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 10000 tons per month

Delivery Time : 30 days

Packaging Details : Gunny bags or cartons and wooden pallet

Contact Now

GNEE RAIL's oval neck track head bolts are manufactured to AREMA specifications with button heads, oval necks and rolled threads. We can also customize track bolts to customer specifications and requirements.

Our oval neck track head bolts can fit standard full toe, toeless, splice bars, style joint bars. They can be used on any type of track including mainline, industrial spurs and sidetracks. The nuts are heavy duty, free fit nuts.

Dimensions:

Diameter: 3/4" to 1-3/8"

Length: 4" to 20"

Drawings:

Precision-Engineered UIC54 Rail Fishplate 4 Holes for Railway Fastening System

Screw Thread d	P	b (min.)	b (max.)	f (min.)	f (max.)	dk (min.)	dk (max.)	kl (min.)	kl (max.)	k (min.)	k(max.)	s (min.)	s (max.)
M10	1.5	19	22	13.3	14	18.35	19.65	4.625	5.375	5.4	6.6	9.42	10.58
M12	1.75	21	24.5	17.3	18	23.35	24.65	6.55	7.45	7.25	8.75	11.3	12.7
M16	2	27	31	21.16	22	29.35	30.65	7.55	8.45	9.25	10.75	15.3	16.7
M20	2.5	29	34	29.16	30	37.2	38.8	9.55	10.45	11.6	13.4	19.16	20.84
M22	2.5	34	39	32	33	41.2	42.8	11.45	12.55	13.1	14.9	21.16	22.84
